VMAN
VMAN CE13BP
The VMAN CE13BP is a 12.8-litre inline-6 diesel engine for generator sets, rated at 535 kVA / 428 kWe standby power at 1,800 RPM (60 Hz). It is a liquid-cooled engine built in China.
- Standby Power · 60 Hz
- 535 kVA
- Electrical Output
- 428 kWe
- Cylinders
- L6
- Displacement
- 12.8 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 450 | 405 | 506.3 |
| Standby Power | 475 | 428 | 535 |
Technical Specifications
| Brand | VMAN |
| Model | CE13BP |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 12.8 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
