VMAN
VMAN D30A3
The VMAN D30A3 is a 29.235-litre V16 diesel engine for generator sets, rated at 878 kVA / 702 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
- Standby Power · 50 Hz
- 878 kVA
- Electrical Output
- 702 kWe
- Cylinders
- V16
- Displacement
- 29.235 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 705 | 635 | 793.8 |
| Standby Power | 780 | 702 | 877.5 |
VMAN D30A3 generator set context
The VMAN D30A3 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 878 kVA / 702 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | VMAN |
| Model | D30A3 |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 29.235 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the VMAN D30A3?
The VMAN D30A3 is rated at 878 kVA standby / 794 kVA prime at 50 Hz (1,500 rpm).
Does the D30A3 run at 50 Hz or 60 Hz?
The VMAN D30A3 is rated for 50 Hz (1,500 rpm).
What fuel does the VMAN D30A3 use?
The VMAN D30A3 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the D30A3?
The VMAN D30A3 is a V16 (16-cylinder) engine with a displacement of 29.235 L.
Is the VMAN D30A3 still in production?
Yes — the VMAN D30A3 is a current production model.
Is a datasheet available for the D30A3?
Yes — an official VMAN datasheet for the VMAN D30A3 can be downloaded from this page.
