VMAN
VMAN D30B3
The VMAN D30B3 is a 29.235-litre V16 diesel engine for generator sets, rated at 1,024 kVA / 819 kWe standby power at 1,800 RPM (60 Hz). It is a liquid-cooled engine built in China.
- Standby Power · 60 Hz
- 1,024 kVA
- Electrical Output
- 819 kWe
- Cylinders
- V16
- Displacement
- 29.235 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 825 | 743 | 928.8 |
| Standby Power | 910 | 819 | 1023.8 |
Technical Specifications
| Brand | VMAN |
| Model | D30B3 |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 29.235 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
