VMAN
VMAN D30B4
The VMAN D30B4 is a 29.235-litre V16 diesel engine for generator sets, rated at 956 kVA / 765 kWe standby power at 1,800 RPM (60 Hz). It is a liquid-cooled engine built in China.
- Standby Power · 60 Hz
- 956 kVA
- Electrical Output
- 765 kWe
- Cylinders
- V16
- Displacement
- 29.235 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 750 | 675 | 843.8 |
| Standby Power | 850 | 765 | 956.3 |
VMAN D30B4 generator set context
The VMAN D30B4 is listed here as a diesel generator-drive engine for 60 Hz generator sets, with a headline 956 kVA / 765 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | VMAN |
| Model | D30B4 |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 29.235 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the VMAN D30B4?
The VMAN D30B4 is rated at 956 kVA standby / 844 kVA prime at 60 Hz (1,800 rpm).
Does the D30B4 run at 50 Hz or 60 Hz?
The VMAN D30B4 is rated for 60 Hz (1,800 rpm).
What fuel does the VMAN D30B4 use?
The VMAN D30B4 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the D30B4?
The VMAN D30B4 is a V16 (16-cylinder) engine with a displacement of 29.235 L.
Is the VMAN D30B4 still in production?
Yes — the VMAN D30B4 is a current production model.
Is a datasheet available for the D30B4?
Yes — an official VMAN datasheet for the VMAN D30B4 can be downloaded from this page.
