VMAN
VMAN D30BP
The VMAN D30BP is a 29.235-litre V16 diesel engine for generator sets, rated at 1,238 kVA / 990 kWe standby power at 1,800 RPM (60 Hz). It is a liquid-cooled engine built in China.
- Standby Power · 60 Hz
- 1,238 kVA
- Electrical Output
- 990 kWe
- Cylinders
- V16
- Displacement
- 29.235 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1000 | 900 | 1125 |
| Standby Power | 1100 | 990 | 1237.5 |
VMAN D30BP generator set context
The VMAN D30BP is listed here as a diesel generator-drive engine for 60 Hz generator sets, with a headline 1,238 kVA / 990 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | VMAN |
| Model | D30BP |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 29.235 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the VMAN D30BP?
The VMAN D30BP is rated at 1,238 kVA standby / 1,125 kVA prime at 60 Hz (1,800 rpm).
Does the D30BP run at 50 Hz or 60 Hz?
The VMAN D30BP is rated for 60 Hz (1,800 rpm).
What fuel does the VMAN D30BP use?
The VMAN D30BP is a diesel generator-set engine.
What is the displacement and cylinder configuration of the D30BP?
The VMAN D30BP is a V16 (16-cylinder) engine with a displacement of 29.235 L.
Is the VMAN D30BP still in production?
Yes — the VMAN D30BP is a current production model.
Is a datasheet available for the D30BP?
Yes — an official VMAN datasheet for the VMAN D30BP can be downloaded from this page.
Related Engines
Reference
- Canonical page
- /engines/vman-d30bp
- Last database update
- 2026-06-08
- Manufacturer files
- 1 datasheet linked
