VMAN
VMAN DE76A2
The VMAN DE76A2 is a 76.3-litre V16 diesel engine for generator sets, rated at 3,128 kVA / 2,502 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
- Standby Power · 50 Hz
- 3,128 kVA
- Electrical Output
- 2,502 kWe
- Cylinders
- V16
- Displacement
- 76.3 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 2510 | 2259 | 2823.8 |
| Standby Power | 2780 | 2502 | 3127.5 |
VMAN DE76A2 generator set context
The VMAN DE76A2 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 3,128 kVA / 2,502 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | VMAN |
| Model | DE76A2 |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 76.3 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the VMAN DE76A2?
The VMAN DE76A2 is rated at 3,128 kVA standby / 2,824 kVA prime at 50 Hz (1,500 rpm).
Does the DE76A2 run at 50 Hz or 60 Hz?
The VMAN DE76A2 is rated for 50 Hz (1,500 rpm).
What fuel does the VMAN DE76A2 use?
The VMAN DE76A2 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DE76A2?
The VMAN DE76A2 is a V16 (16-cylinder) engine with a displacement of 76.3 L.
Is the VMAN DE76A2 still in production?
Yes — the VMAN DE76A2 is a current production model.
Is a datasheet available for the DE76A2?
Yes — an official VMAN datasheet for the VMAN DE76A2 can be downloaded from this page.
Related Engines
Reference
- Canonical page
- /engines/vman-de76a2
- Last database update
- 2026-06-08
- Manufacturer files
- 1 datasheet linked
