VMAN
VMAN DT30
DT Gas
VMAN DT30 — 30 L V16 (130 mm bore) spark-ignited gas generator engine (VMAN DT series). 500 kWe at 1500 rpm / 50 Hz for cogeneration; multi-fuel (natural gas, biogas, LPG).
- Prime Power · 50 Hz
- 625 kVA
- Electrical Output
- 500 kWe
- Cylinders
- V16
- Displacement
- 30.14 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 500 | 625 |
VMAN DT30 generator set context
The VMAN DT30 is listed here as a natural gas generator-drive engine for 50 Hz generator sets, with a headline 625 kVA / 500 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | VMAN |
| Model | DT30 |
| Series | DT Gas |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 30.14 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the VMAN DT30?
The VMAN DT30 is rated at 625 kVA prime at 50 Hz (1,500 rpm).
Does the DT30 run at 50 Hz or 60 Hz?
The VMAN DT30 is rated for 50 Hz (1,500 rpm).
What fuel does the VMAN DT30 use?
The VMAN DT30 is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the DT30?
The VMAN DT30 is a V16 (16-cylinder) engine with a displacement of 30.14 L.
Is the VMAN DT30 still in production?
Yes — the VMAN DT30 is a current production model.
Is a datasheet available for the DT30?
Yes — an official VMAN datasheet for the VMAN DT30 can be downloaded from this page.
