VMAN
VMAN DT30+
DT Gas
VMAN DT30+ — 30 L V16 (130 mm bore) spark-ignited gas generator engine (VMAN DT series), uprated. 550 kWe at 1500 rpm / 50 Hz for cogeneration; multi-fuel (natural gas, biogas, LPG).
- Prime Power · 50 Hz
- 688 kVA
- Electrical Output
- 550 kWe
- Cylinders
- V16
- Displacement
- 30.14 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 550 | 687.5 |
Technical Specifications
| Brand | VMAN |
| Model | DT30+ |
| Series | DT Gas |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 30.14 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
