Weichai WP10D200E200
WP Series
The Weichai WP10D200E200 is a 10-litre inline-6 diesel engine for generator sets, rated at 225 kVA / 180 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Get help with this engine
Tell Haifeng whether you already own a Weichai WP10D200E200 engine/generator or need to source this model for a project.
- Manufacturer files
- 2 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 225 kVA
- Electrical Output
- 180 kWe
- Cylinders
- L6
- Displacement
- 10 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 182.2 | 164 | 205 |
| Standby Power | 200 | 180 | 225 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 182.2 | 164 | 205 |
| Standby Power | 200 | 180 | 225 |
Weichai WP10D200E200 generator set context
The Weichai WP10D200E200 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 225 kVA / 180 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Weichai |
| Model | WP10D200E200 |
| Series | WP Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 10 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage II / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Weichai WP10D200E200?
The Weichai WP10D200E200 is rated at 225 kVA standby / 205 kVA prime at 50 Hz (1,500 rpm); and 225 kVA standby / 205 kVA prime at 60 Hz (1,800 rpm).
Does the WP10D200E200 run at 50 Hz or 60 Hz?
The Weichai WP10D200E200 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Weichai WP10D200E200 use?
The Weichai WP10D200E200 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the WP10D200E200?
The Weichai WP10D200E200 is an inline-6 (6-cylinder) engine with a displacement of 10 L.
Is the Weichai WP10D200E200 still in production?
Yes — the Weichai WP10D200E200 is a current production model.
Is a datasheet available for the WP10D200E200?
Yes — an official Weichai datasheet for the Weichai WP10D200E200 can be downloaded from this page.
