Weichai WP10D238E200

Weichai WP10D238E200 — 10-litre inline-6 diesel engine. Find specifications, documents and parts support below.

Production StatusIn Production

WP Series

Representative Weichai engine
Electrical output 50 Hz · 1500 RPM
Prime power194 kWe
Standby power214 kWe
Configuration
L6
Displacement
10 L
Fuel
Diesel

Power Ratings

kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf

50 Hz1500 RPM

RatingPrimeStandby
Mechanical power kWm216238
Electrical output kWe194214
Apparent power kVA242.5267.5

60 Hz1800 RPM

RatingPrimeStandby
Mechanical power kWm215.6237.8
Electrical output kWe194214
Apparent power kVA242.5267.5

Datasheet & documents

Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.

Source notes

2026-10-21 manufacturer-source revision: Source: 发动机数据单-WP10-0002_WP10D238E200_NonRad无散热器_Datasheet_26-01-01.pdf, p.1.

Gross engine mechanical PRP 216 kW / ESP 238 kW at 1500 rpm.

Net power is configuration-dependent and separate from gross mechanical output; no electrical genset output inferred.

This revision supersedes conflicting rating/duty statements above for the documented configuration; other configurations are not inferred.

Physical specifications added from manufacturer datasheets, 2026-10-21: compression ratio 17:1; dry engine weight 870 kg without radiator and radiator pipes; overall dimensions without radiator (L × W × H) 1873 × 974 × 1300 mm.

Sources: 发动机数据单-WP10-0002_WP10D238E200_NonRad无散热器_Datasheet_26-01-01.pdf (physical data on pp.1–2).

Existing populated specification fields were not overwritten.

Weight is dry engine weight, not genset shipping weight.

View WP10D238E200 spec image
Shareable spec cardWeichai WP10D238E200 summary imageOpen image
Weichai WP10D238E200 10L L6 diesel generator engine — 268 kVA standby specifications

Technical specifications

Technical Specifications

BrandWeichai
ModelWP10D238E200
SeriesWP Series
ConfigurationL6
Cylinders6
Displacement10 L
Compression Ratio17:1
Dry Weight870 kg
Dimensions (L×W×H)1873 × 974 × 1300 mm
Fuel TypeDiesel
Ignition TypeCompression Ignition
Cooling MethodLiquid-Cooled
Emissions StandardChina National Stage II / Unregulated
Country of OriginChina

Check your engine model

The Weichai WP10D238E200 is a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, rated at 268 kVA / 214 kWe / standby rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.

Other ways this model is written

wp10d238e200Weichai WP10D238E200WP Series WP10D238E200

WP10D238E200 repair parts

Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.

Get a parts & air-shipping quote
In-stock parts: same-day dispatch

Worldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.

Find the right part

Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.

Get my parts quote on WhatsApp

We’ll confirm the correct parts, stock and delivery cost before you order.

Opens WhatsApp. Attach photos in the chat.

Photos and details to send
  1. Take a clear photo of the engine nameplate.
  2. Tell us what needs repair or replacement.
  3. Send both in WhatsApp to start a fitment check.
How to read your engine nameplate
Parts reference availability

We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.

Get help with this engine

Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.

Opens WhatsApp. You can edit your message before sending.

Other ways to contact us
Scan QRHide QRHaifeng general WhatsApp chat QR codeGeneral WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales team

Need help after checking the documents?

Send us the part number or describe the problem. This engine model is included in your message.

Send this model enquiry by email

Or browse Haifeng's diesel generator sets

Frequently asked questions

What is the power output of the Weichai WP10D238E200?

The Weichai WP10D238E200 is rated at 268 kVA standby / 243 kVA prime at 50 Hz (1,500 rpm); and 268 kVA standby / 243 kVA prime at 60 Hz (1,800 rpm).

Does the WP10D238E200 run at 50 Hz or 60 Hz?

The Weichai WP10D238E200 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).

What fuel does the Weichai WP10D238E200 use?

The Weichai WP10D238E200 is a diesel generator-set engine.

What is the displacement and cylinder configuration of the WP10D238E200?

The Weichai WP10D238E200 is an inline-6 (6-cylinder) engine with a displacement of 10 L.

What is the catalog status of the Weichai WP10D238E200?

The Weichai WP10D238E200 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.

Are reference documents available for the WP10D238E200?

This page links reference documents for the Weichai WP10D238E200. Check each document's title, model coverage, revision and rating conditions before using it for selection.
