Weichai
Weichai WP10D320E350
WP Series
The Weichai WP10D320E350 is a 10-litre inline-6 diesel engine for generator sets, rated at 360 kVA / 288 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Overhaul & repair parts- Supporting documents
- 2 documents · 1 datasheet
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 360 kVA
- Electrical Output
- 288 kWe
- Cylinders
- L6
- Displacement
- 10 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 290 | 261 | 326.3 |
| Standby Power | 320 | 288 | 360 |
Ask about Weichai WP10D320E350
Choose parts / service or sourcing. Your message includes this model and page link.
Weichai WP10D320E350 overhaul & repair parts
Already running a Weichai WP10D320E350? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with WP10D320E350 and your selected categories included. Attach your photos there.
Weichai WP10D320E350 generator set context
The Weichai WP10D320E350 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 360 kVA / 288 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Weichai |
| Model | WP10D320E350 |
| Series | WP Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 10 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Weichai WP10D320E350?
The Weichai WP10D320E350 is rated at 360 kVA standby / 326 kVA prime at 50 Hz (1,500 rpm).
Does the WP10D320E350 run at 50 Hz or 60 Hz?
The Weichai WP10D320E350 is rated for 50 Hz (1,500 rpm).
What fuel does the Weichai WP10D320E350 use?
The Weichai WP10D320E350 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the WP10D320E350?
The Weichai WP10D320E350 is an inline-6 (6-cylinder) engine with a displacement of 10 L.
What is the catalog status of the Weichai WP10D320E350?
The Weichai WP10D320E350 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the WP10D320E350?
This page links reference documents for the Weichai WP10D320E350. Check each document's title, model coverage, revision and rating conditions before using it for selection.
