Weichai
Weichai WP6D152E310
WP Series
The Weichai WP6D152E310 is a 6.1-litre inline-6 diesel engine for generator sets, rated at 171 kVA / 137 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
- Standby Power · 50 Hz
- 171 kVA
- Electrical Output
- 137 kWe
- Cylinders
- L6
- Displacement
- 6.1 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 137.8 | 124 | 155 |
| Standby Power | 152.2 | 137 | 171.3 |
Technical Specifications
| Brand | Weichai |
| Model | WP6D152E310 |
| Series | WP Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 6.1 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Weichai WP6D152E310?
The Weichai WP6D152E310 is rated at 171 kVA standby / 155 kVA prime at 50 Hz (1,500 rpm).
Does the WP6D152E310 run at 50 Hz or 60 Hz?
The Weichai WP6D152E310 is rated for 50 Hz (1,500 rpm).
What fuel does the Weichai WP6D152E310 use?
The Weichai WP6D152E310 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the WP6D152E310?
The Weichai WP6D152E310 is an inline-6 (6-cylinder) engine with a displacement of 6.1 L.
Is the Weichai WP6D152E310 still in production?
Yes — the Weichai WP6D152E310 is a current production model.
Is a datasheet available for the WP6D152E310?
Yes — an official Weichai datasheet for the Weichai WP6D152E310 can be downloaded from this page.
