Yanmar 3TNV80F-NGGE
Yanmar 3TNV80F-NGGE is a 1.267L L3 3-cylinder diesel generator-drive engine in the TNV F Series, rated at 8.6 kWe standby output at 1,500 rpm / 50 Hz. It is Euro Stage V emissions and built in Japan.
TNV F Series

- Configuration
- L3
- Displacement
- 1.267 L
- Fuel
- Diesel
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| Rating | Standby |
|---|---|
| Mechanical power kWm | 9.6 |
| Electrical output kWe | 8.6 |
| Apparent power kVA | 10.7 |
Datasheet & documents
Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.
Technical specifications
Technical Specifications
| Brand | Yanmar |
| Model | 3TNV80F-NGGE |
| Series | TNV F Series |
| Configuration | L3 |
| Cylinders | 3 |
| Displacement | 1.267 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V |
| Country of Origin | Japan |
Check your engine model
The Yanmar 3TNV80F-NGGE is a diesel generator-drive engine for 50 Hz generator sets, rated at 11 kVA / 9 kWe / standby rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.
Other ways this model is written
3TNV80F-NGGE repair parts
Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.
Get a parts & air-shipping quoteWorldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.
Find the right part
Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.
Other parts? Add them in the chat.
Get my parts quote on WhatsAppWe’ll confirm the correct parts, stock and delivery cost before you order.
Opens WhatsApp. Attach photos in the chat.
Photos and details to send
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Part-number references
Confirm fitment against your engine serial number.
- Piston119E11-22080
Fitment details & source
Yanmar piston assembly
Fitment check: The official Yanmar category title names 3TNV80F-NGGE literally and its product record lists PISTON ASSY 119E11-22080. Confirm the complete engine serial number, installed component specification, and current Yanmar supersession before ordering.
Source: Yanmar US official online parts catalog
- Piston ring set119E10-22500
Fitment details & source
Yanmar piston ring set
Fitment check: The official Yanmar category title names 3TNV80F-NGGE literally and its product record lists RING SET, PISTON 119E10-22500. Confirm the complete engine serial number, installed component specification, and current Yanmar supersession before ordering.
Source: Yanmar US official online parts catalog
Get help with this engine
Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.
Other ways to contact us
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales teamNeed help after checking the documents?
Send us the part number or describe the problem. This engine model is included in your message.
Send this model enquiry by emailOr browse Haifeng's diesel generator sets
Frequently asked questions
What is the power output of the Yanmar 3TNV80F-NGGE?
The Yanmar 3TNV80F-NGGE is rated at 11 kVA standby at 50 Hz (1,500 rpm).
Does the 3TNV80F-NGGE run at 50 Hz or 60 Hz?
The Yanmar 3TNV80F-NGGE is rated for 50 Hz (1,500 rpm).
What fuel does the Yanmar 3TNV80F-NGGE use?
The Yanmar 3TNV80F-NGGE is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 3TNV80F-NGGE?
The Yanmar 3TNV80F-NGGE is an inline-3 (3-cylinder) engine with a displacement of 1.267 L.
What emissions information is listed for the 3TNV80F-NGGE?
This record lists Euro Stage V for the Yanmar 3TNV80F-NGGE. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Yanmar 3TNV80F-NGGE?
The Yanmar 3TNV80F-NGGE is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 3TNV80F-NGGE?
This page links reference documents for the Yanmar 3TNV80F-NGGE. Check each document's title, model coverage, revision and rating conditions before using it for selection.
