Baudouin
Baudouin 12M33G1400/5
12M33 Series
The Baudouin 12M33G1400/5 is a 39.6-litre V12 diesel engine for generator sets, rated at 1,400 kVA / 1,120 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in France.
- Standby Power · 50 Hz
- 1,400 kVA
- Electrical Output
- 1,120 kWe
- Cylinders
- V12
- Displacement
- 39.6 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1100 | 1000 | 1250 |
| Standby Power | 1210 | 1120 | 1400 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1244.4 | 1120 | 1400 |
| Standby Power | 1375.9 | 1238 | 1547.5 |
Technical Specifications
| Brand | Baudouin |
| Model | 12M33G1400/5 |
| Series | 12M33 Series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 39.6 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | France |
Frequently asked questions
What is the power output of the Baudouin 12M33G1400/5?
The Baudouin 12M33G1400/5 is rated at 1,400 kVA standby / 1,250 kVA prime at 50 Hz (1,500 rpm); and 1,548 kVA standby / 1,400 kVA prime at 60 Hz (1,800 rpm).
Does the 12M33G1400/5 run at 50 Hz or 60 Hz?
The Baudouin 12M33G1400/5 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Baudouin 12M33G1400/5 use?
The Baudouin 12M33G1400/5 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 12M33G1400/5?
The Baudouin 12M33G1400/5 is a V12 (12-cylinder) engine with a displacement of 39.6 L.
Is the Baudouin 12M33G1400/5 still in production?
Yes — the Baudouin 12M33G1400/5 is a current production model.
Is a datasheet available for the 12M33G1400/5?
Yes — an official Baudouin datasheet for the Baudouin 12M33G1400/5 can be downloaded from this page.
Related Engines
Compare Baudouin 12M33G1400/5
Reference
- Canonical page
- /engines/baudouin-12m33g1400-5
- Last database update
- 2026-06-07
- Manufacturer files
- 2 datasheets linked
