Baudouin
Baudouin 12M33G1500/5
12M33 Series
The Baudouin 12M33G1500/5 is a 39.6-litre V12 diesel engine for generator sets, rated at 1,500 kVA / 1,200 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in France.
Overhaul & repair parts- Supporting documents
- 1 document · 1 datasheet
- Last updated
- 2026-06-07
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 1,500 kVA
- Electrical Output
- 1,200 kWe
- Cylinders
- V12
- Displacement
- 39.6 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1200 | 1100 | 1375 |
| Standby Power | 1320 | 1200 | 1500 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1333.3 | 1200 | 1500 |
| Standby Power | 1473.5 | 1326 | 1657.5 |
Ask about Baudouin 12M33G1500/5
Choose parts / service or sourcing. Your message includes this model and page link.
Baudouin 12M33G1500/5 overhaul & repair parts
Already running a Baudouin 12M33G1500/5? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 12M33G1500/5 and your selected categories included. Attach your photos there.
Baudouin 12M33G1500/5 generator set context
The Baudouin 12M33G1500/5 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 1,500 kVA / 1,200 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Baudouin |
| Model | 12M33G1500/5 |
| Series | 12M33 Series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 39.6 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | France |
Frequently asked questions
What is the power output of the Baudouin 12M33G1500/5?
The Baudouin 12M33G1500/5 is rated at 1,500 kVA standby / 1,375 kVA prime at 50 Hz (1,500 rpm); and 1,658 kVA standby / 1,500 kVA prime at 60 Hz (1,800 rpm).
Does the 12M33G1500/5 run at 50 Hz or 60 Hz?
The Baudouin 12M33G1500/5 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Baudouin 12M33G1500/5 use?
The Baudouin 12M33G1500/5 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 12M33G1500/5?
The Baudouin 12M33G1500/5 is a V12 (12-cylinder) engine with a displacement of 39.6 L.
What is the catalog status of the Baudouin 12M33G1500/5?
The Baudouin 12M33G1500/5 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 12M33G1500/5?
This page links reference documents for the Baudouin 12M33G1500/5. Check each document's title, model coverage, revision and rating conditions before using it for selection.
