Baudouin
Baudouin 12M33G1650/5
12M33 Series
The Baudouin 12M33G1650/5 is a 39.6-litre V12 diesel engine for generator sets, rated at 1,650 kVA / 1,320 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in France.
Overhaul & repair parts- Supporting documents
- 1 document · 1 datasheet
- Last updated
- 2026-06-07
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 1,650 kVA
- Electrical Output
- 1,320 kWe
- Cylinders
- V12
- Displacement
- 39.6 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1350 | 1200 | 1500 |
| Standby Power | 1450 | 1320 | 1650 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1466.7 | 1320 | 1650 |
| Standby Power | 1580.3 | 1422 | 1777.5 |
Ask about Baudouin 12M33G1650/5
Choose parts / service or sourcing. Your message includes this model and page link.
Baudouin 12M33G1650/5 overhaul & repair parts
Already running a Baudouin 12M33G1650/5? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 12M33G1650/5 and your selected categories included. Attach your photos there.
Baudouin 12M33G1650/5 generator set context
The Baudouin 12M33G1650/5 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 1,650 kVA / 1,320 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Baudouin |
| Model | 12M33G1650/5 |
| Series | 12M33 Series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 39.6 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | France |
Frequently asked questions
What is the power output of the Baudouin 12M33G1650/5?
The Baudouin 12M33G1650/5 is rated at 1,650 kVA standby / 1,500 kVA prime at 50 Hz (1,500 rpm); and 1,778 kVA standby / 1,650 kVA prime at 60 Hz (1,800 rpm).
Does the 12M33G1650/5 run at 50 Hz or 60 Hz?
The Baudouin 12M33G1650/5 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Baudouin 12M33G1650/5 use?
The Baudouin 12M33G1650/5 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 12M33G1650/5?
The Baudouin 12M33G1650/5 is a V12 (12-cylinder) engine with a displacement of 39.6 L.
What is the catalog status of the Baudouin 12M33G1650/5?
The Baudouin 12M33G1650/5 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 12M33G1650/5?
This page links reference documents for the Baudouin 12M33G1650/5. Check each document's title, model coverage, revision and rating conditions before using it for selection.
