Baudouin
Baudouin 4M10G4D0/S
4M10
Baudouin 4M10G4D0/S generator-drive diesel engine discovered in the GenProBase public selector. GenProBase lists 2 row(s) across 50Hz, 60Hz with 4.087 L displacement, 4L cylinders, liquid-cooled cooling, and Unregulated emissions labeling. Treat this row as source-discovered and prioritize OEM datasheet attachment in a follow-up pass.
Chat on WhatsApp about this engine
Opens WhatsApp with Baudouin 4M10G4D0/S and this page link filled in.
- Manufacturer files
- No datasheet
- Last updated
- 2026-08-05
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 88 kVA
- Electrical Output
- 70 kWe
- Cylinders
- L4
- Displacement
- 4.087 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 72 | 64 | — |
| Standby Power | 80 | 70 | — |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 85 | 75 | — |
| Standby Power | 95 | 83 | — |
Baudouin 4M10G4D0/S generator set context
The Baudouin 4M10G4D0/S is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 88 kVA / 70 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Baudouin |
| Model | 4M10G4D0/S |
| Series | 4M10 |
| Configuration | L4, turbocharged |
| Cylinders | 4 |
| Displacement | 4.087 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Baudouin 4M10G4D0/S?
The Baudouin 4M10G4D0/S is rated at 88 kVA standby / 80 kVA prime at 50 Hz (1,500 rpm); and 104 kVA standby / 94 kVA prime at 60 Hz (1,800 rpm).
Does the 4M10G4D0/S run at 50 Hz or 60 Hz?
The Baudouin 4M10G4D0/S is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Baudouin 4M10G4D0/S use?
The Baudouin 4M10G4D0/S is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 4M10G4D0/S?
The Baudouin 4M10G4D0/S is an inline-4 (4-cylinder) engine with a displacement of 4.087 L.
Is the Baudouin 4M10G4D0/S still in production?
Yes — the Baudouin 4M10G4D0/S is a current production model.
