Baudouin 4M10G6D0/S generator-drive diesel engine discovered in the GenProBase public selector. GenProBase lists 2 row(s) across 50Hz, 60Hz with 4.087 L displacement, 4L cylinders, liquid-cooled cooling, and Unregulated emissions labeling. Treat this row as source-discovered and prioritize OEM datasheet attachment in a follow-up pass.
Production StatusIn Production
4M10
- Configuration
- L4, turbocharged aftercooled
- Displacement
- 4.087 L
- Fuel
- Diesel
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| Rating | Prime | Standby |
|---|---|---|
| Mechanical power kWm | 90 | 100 |
| Electrical output kWe | 80 | 88 |
60 Hz1800 RPM
| Rating | Prime | Standby |
|---|---|---|
| Mechanical power kWm | 105 | 115 |
| Electrical output kWe | 90 | 100 |
Datasheet & documents
Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.
Technical specifications
Technical Specifications
| Brand | Baudouin |
| Model | 4M10G6D0/S |
| Series | 4M10 |
| Configuration | L4, turbocharged aftercooled |
| Cylinders | 4 |
| Displacement | 4.087 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Check your engine model
The Baudouin 4M10G6D0/S is a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, rated at 110 kVA / 88 kWe / standby rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.
Other ways this model is written
4m10g6d0s4M10G6D0 SBaudouin 4M10G6D0/S
4M10G6D0/S repair parts
Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.
Get a parts & air-shipping quoteIn-stock parts: same-day dispatch
Worldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.
Find the right part
Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.
Get my parts quote on WhatsAppWe’ll confirm the correct parts, stock and delivery cost before you order.
Opens WhatsApp. Attach photos in the chat.
Photos and details to send
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Parts reference availability
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Get help with this engine
Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.
Other ways to contact us
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales teamNeed help after checking the documents?
Send us the part number or describe the problem. This engine model is included in your message.
Send this model enquiry by emailOr browse Haifeng's diesel generator sets
Frequently asked questions
What is the power output of the Baudouin 4M10G6D0/S?
The Baudouin 4M10G6D0/S is rated at 110 kVA standby / 100 kVA prime at 50 Hz (1,500 rpm); and 125 kVA standby / 113 kVA prime at 60 Hz (1,800 rpm).
Does the 4M10G6D0/S run at 50 Hz or 60 Hz?
The Baudouin 4M10G6D0/S is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Baudouin 4M10G6D0/S use?
The Baudouin 4M10G6D0/S is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 4M10G6D0/S?
The Baudouin 4M10G6D0/S is an inline-4 (4-cylinder) engine with a displacement of 4.087 L.
What is the catalog status of the Baudouin 4M10G6D0/S?
The Baudouin 4M10G6D0/S is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
