Cummins
Cummins KTA38-G9A
K38 Series
The Cummins KTA38-G9A is a 38-litre V12 diesel engine for generator sets, rated at 1,375 kVA / 1,100 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
- Standby Power · 50 Hz
- 1,375 kVA
- Electrical Output
- 1,100 kWe
- Cylinders
- V12
- Displacement
- 38 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1111.1 | 1000 | 1250 |
| Standby Power | 1222.2 | 1100 | 1375 |
Technical Specifications
| Brand | Cummins |
| Model | KTA38-G9A |
| Series | K38 Series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 38 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Cummins KTA38-G9A?
The Cummins KTA38-G9A is rated at 1,375 kVA standby / 1,250 kVA prime at 50 Hz (1,500 rpm).
Does the KTA38-G9A run at 50 Hz or 60 Hz?
The Cummins KTA38-G9A is rated for 50 Hz (1,500 rpm).
What fuel does the Cummins KTA38-G9A use?
The Cummins KTA38-G9A is a diesel generator-set engine.
What is the displacement and cylinder configuration of the KTA38-G9A?
The Cummins KTA38-G9A is a V12 (12-cylinder) engine with a displacement of 38 L.
Is the Cummins KTA38-G9A still in production?
Yes — the Cummins KTA38-G9A is a current production model.
Is a datasheet available for the KTA38-G9A?
Yes — an official Cummins datasheet for the Cummins KTA38-G9A can be downloaded from this page.
