Googol
Googol QTA20V-EG3100D
Q Series
The Googol QTA20V-EG3100D is a 107.5-litre V20 diesel engine for generator sets, rated at 3,438 kVA / 2,750 kWe standby power at 1,500 RPM (50 Hz). It is a water-air-cooled engine built in China.
Overhaul & repair parts- Supporting documents
- 2 documents · 1 datasheet
- Last updated
- 2026-06-07
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 3,438 kVA
- Electrical Output
- 2,750 kWe
- Cylinders
- V20
- Displacement
- 107.5 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 2777.8 | 2500 | 3125 |
| Standby Power | 3055.6 | 2750 | 3437.5 |
Ask about Googol QTA20V-EG3100D
Choose parts / service or sourcing. Your message includes this model and page link.
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales teamGoogol QTA20V-EG3100D overhaul & repair parts
Already running a Googol QTA20V-EG3100D? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with QTA20V-EG3100D and your selected categories included. Attach your photos there.
Googol QTA20V-EG3100D generator set context
The Googol QTA20V-EG3100D is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 3,438 kVA / 2,750 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Googol |
| Model | QTA20V-EG3100D |
| Series | Q Series |
| Configuration | V20 |
| Cylinders | 20 |
| Displacement | 107.5 L |
| Dry Weight | 7800 kg |
| Dimensions (L×W×H) | 4170 × 1634 × 2130 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Water-Air |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Googol QTA20V-EG3100D?
The Googol QTA20V-EG3100D is rated at 3,438 kVA standby / 3,125 kVA prime at 50 Hz (1,500 rpm).
Does the QTA20V-EG3100D run at 50 Hz or 60 Hz?
The Googol QTA20V-EG3100D is rated for 50 Hz (1,500 rpm).
What fuel does the Googol QTA20V-EG3100D use?
The Googol QTA20V-EG3100D is a diesel generator-set engine.
What is the displacement and cylinder configuration of the QTA20V-EG3100D?
The Googol QTA20V-EG3100D is a V20 (20-cylinder) engine with a displacement of 107.5 L.
What is the catalog status of the Googol QTA20V-EG3100D?
The Googol QTA20V-EG3100D is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the QTA20V-EG3100D?
This page links reference documents for the Googol QTA20V-EG3100D. Check each document's title, model coverage, revision and rating conditions before using it for selection.
