Googol
Googol QTAA16V-EG2440
Q Series
The Googol QTAA16V-EG2440 is a 86-litre V16 diesel engine for generator sets, rated at 2,750 kVA / 2,200 kWe standby power at 1,500 RPM (50 Hz). It is a air-air-cooled engine built in China.
- Standby Power · 50 Hz
- 2,750 kVA
- Electrical Output
- 2,200 kWe
- Cylinders
- V16
- Displacement
- 86 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 2222.2 | 2000 | 2500 |
| Standby Power | 2444.4 | 2200 | 2750 |
Technical Specifications
| Brand | Googol |
| Model | QTAA16V-EG2440 |
| Series | Q Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 86 L |
| Dry Weight | 6160 kg |
| Dimensions (L×W×H) | 3172 × 1950 × 2340 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Air-Air |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Googol QTAA16V-EG2440?
The Googol QTAA16V-EG2440 is rated at 2,750 kVA standby / 2,500 kVA prime at 50 Hz (1,500 rpm).
Does the QTAA16V-EG2440 run at 50 Hz or 60 Hz?
The Googol QTAA16V-EG2440 is rated for 50 Hz (1,500 rpm).
What fuel does the Googol QTAA16V-EG2440 use?
The Googol QTAA16V-EG2440 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the QTAA16V-EG2440?
The Googol QTAA16V-EG2440 is a V16 (16-cylinder) engine with a displacement of 86 L.
Is the Googol QTAA16V-EG2440 still in production?
Yes — the Googol QTAA16V-EG2440 is a current production model.
Is a datasheet available for the QTAA16V-EG2440?
Yes — an official Googol datasheet for the Googol QTAA16V-EG2440 can be downloaded from this page.
