Googol
Googol QTAA20V-EG3330
Q Series
The Googol QTAA20V-EG3330 is a 107.5-litre V20 diesel engine for generator sets, rated at 3,750 kVA / 3,000 kWe standby power at 1,500 RPM (50 Hz). It is a air-air-cooled engine built in China.
Get help with this engine
Tell Haifeng whether you already own a Googol QTAA20V-EG3330 engine/generator or need to source this model for a project.
- Manufacturer files
- 2 datasheets
- Last updated
- 2026-06-07
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 3,750 kVA
- Electrical Output
- 3,000 kWe
- Cylinders
- V20
- Displacement
- 107.5 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 3000 | 2700 | 3375 |
| Standby Power | 3333.3 | 3000 | 3750 |
Googol QTAA20V-EG3330 generator set context
The Googol QTAA20V-EG3330 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 3,750 kVA / 3,000 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Googol |
| Model | QTAA20V-EG3330 |
| Series | Q Series |
| Configuration | V20 |
| Cylinders | 20 |
| Displacement | 107.5 L |
| Dry Weight | 7550 kg |
| Dimensions (L×W×H) | 3688 × 1950 × 2340 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Air-Air |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Googol QTAA20V-EG3330?
The Googol QTAA20V-EG3330 is rated at 3,750 kVA standby / 3,375 kVA prime at 50 Hz (1,500 rpm).
Does the QTAA20V-EG3330 run at 50 Hz or 60 Hz?
The Googol QTAA20V-EG3330 is rated for 50 Hz (1,500 rpm).
What fuel does the Googol QTAA20V-EG3330 use?
The Googol QTAA20V-EG3330 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the QTAA20V-EG3330?
The Googol QTAA20V-EG3330 is a V20 (20-cylinder) engine with a displacement of 107.5 L.
Is the Googol QTAA20V-EG3330 still in production?
Yes — the Googol QTAA20V-EG3330 is a current production model.
Is a datasheet available for the QTAA20V-EG3330?
Yes — an official Googol datasheet for the Googol QTAA20V-EG3330 can be downloaded from this page.
