Hatz
2M41
41 Series
Hatz 2M41 1.6L (approx.) 2-cylinder diesel engine for generator sets. 14 kWe standby at 50Hz / 17.5 kWe at 60Hz. Euro Stage IIIA.
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 14.1 | 12.7 | 15.9 |
| Standby Power | 15.6 | 14 | 17.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 17.4 | 15.7 | 19.6 |
| Standby Power | 19.4 | 17.5 | 21.9 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Technical Specifications
| Brand | Hatz |
| Model | 2M41 |
| Series | 41 Series |
| Configuration | In-line 2, Air-cooled |
| Cylinders | 2 |
| Displacement | 1.6 L |
| Fuel Type | Diesel |
| Emissions Standard | Euro Stage IIIA |
| Country of Origin | Germany |
