Hatz
4L41C
41 Series
Hatz 4L41C 3.1L (approx.) 4-cylinder diesel engine for generator sets. 27 kWe standby at 50Hz / 33 kWe at 60Hz. Euro Stage IIIA.
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 26.7 | 24 | 30 |
| Standby Power | 30 | 27 | 33.8 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 33.3 | 30 | 37.5 |
| Standby Power | 36.7 | 33 | 41.3 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Technical Specifications
| Brand | Hatz |
| Model | 4L41C |
| Series | 41 Series |
| Configuration | In-line 4, Air-cooled |
| Cylinders | 4 |
| Displacement | 3.1 L |
| Fuel Type | Diesel |
| Emissions Standard | Euro Stage IIIA |
| Country of Origin | Germany |
