Hatz
3M41
41 Series
Hatz 3M41 2.5L (approx.) 3-cylinder diesel engine for generator sets. 22 kWe standby at 50Hz / 28 kWe at 60Hz. Euro Stage IIIA.
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 22.2 | 20 | 25 |
| Standby Power | 24.4 | 22 | 27.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 27.8 | 25 | 31.3 |
| Standby Power | 31.1 | 28 | 35 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Technical Specifications
| Brand | Hatz |
| Model | 3M41 |
| Series | 41 Series |
| Configuration | In-line 3, Air-cooled |
| Cylinders | 3 |
| Displacement | 2.5 L |
| Fuel Type | Diesel |
| Emissions Standard | Euro Stage IIIA |
| Country of Origin | Germany |
