Hyundai
Hyundai DP054CCV
DP054 Series
Hyundai DP054CCV 5L 4-cylinder diesel engine for generator sets. Euro Stage V certified.
Chat on WhatsApp about this engine
Opens WhatsApp with Hyundai DP054CCV and this page link filled in.
- Manufacturer files
- 4 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 206 kVA
- Electrical Output
- 165 kWe
- Cylinders
- L4
- Displacement
- 5 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 177.8 | 160 | 200 |
| Standby Power | 183.3 | 165 | 206.3 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 194.4 | 175 | 218.8 |
| Standby Power | 196.7 | 177 | 221.3 |
Hyundai DP054CCV generator set context
The Hyundai DP054CCV is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 206 kVA / 165 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP054CCV |
| Series | DP054 Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 5 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP054CCV?
The Hyundai DP054CCV is rated at 206 kVA standby / 200 kVA prime at 50 Hz (1,500 rpm); and 221 kVA standby / 219 kVA prime at 60 Hz (1,800 rpm).
Does the DP054CCV run at 50 Hz or 60 Hz?
The Hyundai DP054CCV is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP054CCV use?
The Hyundai DP054CCV is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP054CCV?
The Hyundai DP054CCV is an inline-4 (4-cylinder) engine with a displacement of 5 L.
What emissions standard does the DP054CCV meet?
The Hyundai DP054CCV is certified to Euro Stage V emissions standards.
Is the Hyundai DP054CCV still in production?
Yes — the Hyundai DP054CCV is a current production model.
Is a datasheet available for the DP054CCV?
Yes — an official Hyundai datasheet for the Hyundai DP054CCV can be downloaded from this page.
