Hyundai
Hyundai DP086CB
DP086 Series
Hyundai DP086CB 7.5L 6-cylinder diesel engine for generator sets. Unregulated (no emission certification).
Chat on WhatsApp about this engine
Opens WhatsApp with Hyundai DP086CB and this page link filled in.
- Manufacturer files
- 4 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 256 kVA
- Electrical Output
- 205 kWe
- Cylinders
- L6
- Displacement
- 7.5 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 206.7 | 186 | 232.5 |
| Standby Power | 227.8 | 205 | 256.3 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 234.4 | 211 | 263.8 |
| Standby Power | 260 | 234 | 292.5 |
Hyundai DP086CB generator set context
The Hyundai DP086CB is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 256 kVA / 205 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP086CB |
| Series | DP086 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 7.5 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP086CB?
The Hyundai DP086CB is rated at 256 kVA standby / 233 kVA prime at 50 Hz (1,500 rpm); and 293 kVA standby / 264 kVA prime at 60 Hz (1,800 rpm).
Does the DP086CB run at 50 Hz or 60 Hz?
The Hyundai DP086CB is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP086CB use?
The Hyundai DP086CB is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP086CB?
The Hyundai DP086CB is an inline-6 (6-cylinder) engine with a displacement of 7.5 L.
Is the Hyundai DP086CB still in production?
Yes — the Hyundai DP086CB is a current production model.
Is a datasheet available for the DP086CB?
Yes — an official Hyundai datasheet for the Hyundai DP086CB can be downloaded from this page.
