Hyundai
Hyundai DP086CC
DP086 Series
Hyundai DP086CC 7.5L 6-cylinder diesel engine for generator sets. Unregulated (no emission certification).
Chat on WhatsApp about this engine
Opens WhatsApp with Hyundai DP086CC and this page link filled in.
- Manufacturer files
- 4 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 280 kVA
- Electrical Output
- 224 kWe
- Cylinders
- L6
- Displacement
- 7.5 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 225.6 | 203 | 253.8 |
| Standby Power | 248.9 | 224 | 280 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 258.9 | 233 | 291.3 |
| Standby Power | 285.6 | 257 | 321.3 |
Hyundai DP086CC generator set context
The Hyundai DP086CC is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 280 kVA / 224 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP086CC |
| Series | DP086 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 7.5 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP086CC?
The Hyundai DP086CC is rated at 280 kVA standby / 254 kVA prime at 50 Hz (1,500 rpm); and 321 kVA standby / 291 kVA prime at 60 Hz (1,800 rpm).
Does the DP086CC run at 50 Hz or 60 Hz?
The Hyundai DP086CC is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP086CC use?
The Hyundai DP086CC is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP086CC?
The Hyundai DP086CC is an inline-6 (6-cylinder) engine with a displacement of 7.5 L.
Is the Hyundai DP086CC still in production?
Yes — the Hyundai DP086CC is a current production model.
Is a datasheet available for the DP086CC?
Yes — an official Hyundai datasheet for the Hyundai DP086CC can be downloaded from this page.
