Hyundai
Hyundai DP086CD
DP086 Series
Hyundai DP086CD 7.5L 6-cylinder diesel engine for generator sets. Unregulated (no emission certification).
Chat on WhatsApp about this engine
Opens WhatsApp with Hyundai DP086CD and this page link filled in.
- Manufacturer files
- 4 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 309 kVA
- Electrical Output
- 247 kWe
- Cylinders
- L6
- Displacement
- 7.5 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 248.9 | 224 | 280 |
| Standby Power | 274.4 | 247 | 308.8 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 282.2 | 254 | 317.5 |
| Standby Power | 311.1 | 280 | 350 |
Hyundai DP086CD generator set context
The Hyundai DP086CD is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 309 kVA / 247 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP086CD |
| Series | DP086 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 7.5 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP086CD?
The Hyundai DP086CD is rated at 309 kVA standby / 280 kVA prime at 50 Hz (1,500 rpm); and 350 kVA standby / 318 kVA prime at 60 Hz (1,800 rpm).
Does the DP086CD run at 50 Hz or 60 Hz?
The Hyundai DP086CD is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP086CD use?
The Hyundai DP086CD is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP086CD?
The Hyundai DP086CD is an inline-6 (6-cylinder) engine with a displacement of 7.5 L.
Is the Hyundai DP086CD still in production?
Yes — the Hyundai DP086CD is a current production model.
Is a datasheet available for the DP086CD?
Yes — an official Hyundai datasheet for the Hyundai DP086CD can be downloaded from this page.
