Hyundai
Hyundai DP158CC
DP158 Series
Hyundai DP158CC 15.1L diesel engine for generator sets. Unregulated (no emission certification).
Chat on WhatsApp about this engine
Opens WhatsApp with Hyundai DP158CC and this page link filled in.
- Manufacturer files
- 4 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 620 kVA
- Electrical Output
- 496 kWe
- Cylinders
- L6
- Displacement
- 15.1 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 500 | 450 | 562.5 |
| Standby Power | 551.1 | 496 | 620 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 562.2 | 506 | 632.5 |
| Standby Power | 620 | 558 | 697.5 |
Hyundai DP158CC generator set context
The Hyundai DP158CC is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 620 kVA / 496 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP158CC |
| Series | DP158 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 15.1 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP158CC?
The Hyundai DP158CC is rated at 620 kVA standby / 563 kVA prime at 50 Hz (1,500 rpm); and 698 kVA standby / 633 kVA prime at 60 Hz (1,800 rpm).
Does the DP158CC run at 50 Hz or 60 Hz?
The Hyundai DP158CC is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP158CC use?
The Hyundai DP158CC is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP158CC?
The Hyundai DP158CC is an inline-6 (6-cylinder) engine with a displacement of 15.1 L.
Is the Hyundai DP158CC still in production?
Yes — the Hyundai DP158CC is a current production model.
Is a datasheet available for the DP158CC?
Yes — an official Hyundai datasheet for the Hyundai DP158CC can be downloaded from this page.
