Haifeng Machinery

Hyundai DP158LD

Hyundai DP158LD 15.1L 8-cylinder diesel engine for generator sets. Unregulated (no emission certification).

Production StatusIn Production

DP158 Series

Representative Hyundai engine
Electrical output 50 Hz · 1500 RPM
Prime power423 kWe
Standby power466 kWe
Configuration
V8
Displacement
15.1 L
Fuel
Diesel

Power Ratings

kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf

50 Hz1500 RPM

RatingPrimeStandby
Mechanical power kWm470517.8
Electrical output kWe423466
Apparent power kVA528.8582.5

60 Hz1800 RPM

RatingPrimeStandby
Mechanical power kWm503.3556.7
Electrical output kWe453501
Apparent power kVA566.3626.3

Datasheet & documents

Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.

Technical specifications

Technical Specifications

BrandHyundai
ModelDP158LD
SeriesDP158 Series
ConfigurationV8
Cylinders8
Displacement15.1 L
Fuel TypeDiesel
Ignition TypeCompression Ignition
Cooling MethodLiquid-Cooled
Emissions StandardUnregulated
Country of OriginSouth Korea

Check your engine model

The Hyundai DP158LD is a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, rated at 583 kVA / 466 kWe / standby rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.

Other ways this model is written

dp158ldHyundai DP158LDDP158 Series DP158LD

DP158LD repair parts

Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.

Get a parts & air-shipping quote
In-stock parts: same-day dispatch

Worldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.

Find the right part

Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.

Which parts do you need?

Other parts? Add them in the chat.

Get my parts quote on WhatsApp

We’ll confirm the correct parts, stock and delivery cost before you order.

Opens WhatsApp. Attach photos in the chat.

Photos and details to send
  1. Take a clear photo of the engine nameplate.
  2. Tell us what needs repair or replacement.
  3. Send both in WhatsApp to start a fitment check.
How to read your engine nameplate

These categories have model-related records. Part numbers need further checking before we display them here.

Get help with this engine

Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.

Opens WhatsApp. You can edit your message before sending.

Other ways to contact us
Scan QRHide QRHaifeng general WhatsApp chat QR codeGeneral WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales team

Need help after checking the documents?

Send us the part number or describe the problem. This engine model is included in your message.

Send this model enquiry by email

Or browse Haifeng's diesel generator sets

Frequently asked questions

What is the power output of the Hyundai DP158LD?

The Hyundai DP158LD is rated at 583 kVA standby / 529 kVA prime at 50 Hz (1,500 rpm); and 626 kVA standby / 566 kVA prime at 60 Hz (1,800 rpm).

Does the DP158LD run at 50 Hz or 60 Hz?

The Hyundai DP158LD is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).

What fuel does the Hyundai DP158LD use?

The Hyundai DP158LD is a diesel generator-set engine.

What is the displacement and cylinder configuration of the DP158LD?

The Hyundai DP158LD is a V8 (8-cylinder) engine with a displacement of 15.1 L.

What is the catalog status of the Hyundai DP158LD?

The Hyundai DP158LD is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.

Are reference documents available for the DP158LD?

This page links reference documents for the Hyundai DP158LD. Check each document's title, model coverage, revision and rating conditions before using it for selection.
