Hyundai DP158CD
DP158 Series
Hyundai DP158CD 15.1L diesel engine for generator sets. Unregulated (no emission certification).
Chat on WhatsApp about this engine
Opens WhatsApp with Hyundai DP158CD and this page link filled in.
- Manufacturer files
- 4 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 703 kVA
- Electrical Output
- 562 kWe
- Cylinders
- L6
- Displacement
- 15.1 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 565.6 | 509 | 636.3 |
| Standby Power | 624.4 | 562 | 702.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 611.1 | 550 | 687.5 |
| Standby Power | 666.7 | 600 | 750 |
Hyundai DP158CD generator set context
The Hyundai DP158CD is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 703 kVA / 562 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP158CD |
| Series | DP158 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 15.1 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP158CD?
The Hyundai DP158CD is rated at 703 kVA standby / 636 kVA prime at 50 Hz (1,500 rpm); and 750 kVA standby / 688 kVA prime at 60 Hz (1,800 rpm).
Does the DP158CD run at 50 Hz or 60 Hz?
The Hyundai DP158CD is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP158CD use?
The Hyundai DP158CD is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP158CD?
The Hyundai DP158CD is an inline-6 (6-cylinder) engine with a displacement of 15.1 L.
Is the Hyundai DP158CD still in production?
Yes — the Hyundai DP158CD is a current production model.
Is a datasheet available for the DP158CD?
Yes — an official Hyundai datasheet for the Hyundai DP158CD can be downloaded from this page.
