Hyundai
Hyundai DP222CA
DP222 Series
Hyundai DP222CA 21.9L 12-cylinder diesel engine for generator sets. Unregulated (no emission certification).
Chat on WhatsApp about this engine
Opens WhatsApp with Hyundai DP222CA and this page link filled in.
- Manufacturer files
- 3 datasheets
- Last updated
- 2026-06-28
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 834 kVA
- Electrical Output
- 667 kWe
- Cylinders
- V12
- Displacement
- 21.9 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 675.6 | 608 | 760 |
| Standby Power | 741.1 | 667 | 833.8 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 761.1 | 685 | 856.3 |
| Standby Power | 838.9 | 755 | 943.8 |
Hyundai DP222CA generator set context
The Hyundai DP222CA is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 834 kVA / 667 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP222CA |
| Series | DP222 Series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 21.9 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP222CA?
The Hyundai DP222CA is rated at 834 kVA standby / 760 kVA prime at 50 Hz (1,500 rpm); and 944 kVA standby / 856 kVA prime at 60 Hz (1,800 rpm).
Does the DP222CA run at 50 Hz or 60 Hz?
The Hyundai DP222CA is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP222CA use?
The Hyundai DP222CA is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP222CA?
The Hyundai DP222CA is a V12 (12-cylinder) engine with a displacement of 21.9 L.
Is the Hyundai DP222CA still in production?
Yes — the Hyundai DP222CA is a current production model.
Is a datasheet available for the DP222CA?
Yes — an official Hyundai datasheet for the Hyundai DP222CA can be downloaded from this page.
