Hyundai
Hyundai DP222LC
DP222 Series
Hyundai DP222LC 21.9L 12-cylinder diesel engine for generator sets. Unregulated (no emission certification).
Chat on WhatsApp about this engine
Opens WhatsApp with Hyundai DP222LC and this page link filled in.
- Manufacturer files
- 4 datasheets
- Last updated
- 2026-06-28
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 828 kVA
- Electrical Output
- 662 kWe
- Cylinders
- V12
- Displacement
- 21.9 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 665.6 | 599 | 748.8 |
| Standby Power | 735.6 | 662 | 827.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 751.1 | 676 | 845 |
| Standby Power | 830 | 747 | 933.8 |
Hyundai DP222LC generator set context
The Hyundai DP222LC is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 828 kVA / 662 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP222LC |
| Series | DP222 Series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 21.9 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP222LC?
The Hyundai DP222LC is rated at 828 kVA standby / 749 kVA prime at 50 Hz (1,500 rpm); and 934 kVA standby / 845 kVA prime at 60 Hz (1,800 rpm).
Does the DP222LC run at 50 Hz or 60 Hz?
The Hyundai DP222LC is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP222LC use?
The Hyundai DP222LC is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP222LC?
The Hyundai DP222LC is a V12 (12-cylinder) engine with a displacement of 21.9 L.
Is the Hyundai DP222LC still in production?
Yes — the Hyundai DP222LC is a current production model.
Is a datasheet available for the DP222LC?
Yes — an official Hyundai datasheet for the Hyundai DP222LC can be downloaded from this page.
