Hyundai
Hyundai DP222LB
DP222 Series
Hyundai DP222LB 21.9L 12-cylinder diesel engine for generator sets. Unregulated (no emission certification).
Overhaul & repair parts- Supporting documents
- 4 documents · 2 datasheets
- Last updated
- 2026-06-28
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 758 kVA
- Electrical Output
- 606 kWe
- Cylinders
- V12
- Displacement
- 21.9 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 610 | 549 | 686.3 |
| Standby Power | 673.3 | 606 | 757.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 706.7 | 636 | 795 |
| Standby Power | 781.1 | 703 | 878.8 |
Ask about Hyundai DP222LB
Choose parts / service or sourcing. Your message includes this model and page link.
Hyundai DP222LB overhaul & repair parts
Already running a Hyundai DP222LB? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with DP222LB and your selected categories included. Attach your photos there.
Hyundai DP222LB generator set context
The Hyundai DP222LB is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 758 kVA / 606 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP222LB |
| Series | DP222 Series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 21.9 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP222LB?
The Hyundai DP222LB is rated at 758 kVA standby / 686 kVA prime at 50 Hz (1,500 rpm); and 879 kVA standby / 795 kVA prime at 60 Hz (1,800 rpm).
Does the DP222LB run at 50 Hz or 60 Hz?
The Hyundai DP222LB is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP222LB use?
The Hyundai DP222LB is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP222LB?
The Hyundai DP222LB is a V12 (12-cylinder) engine with a displacement of 21.9 L.
What is the catalog status of the Hyundai DP222LB?
The Hyundai DP222LB is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the DP222LB?
This page links reference documents for the Hyundai DP222LB. Check each document's title, model coverage, revision and rating conditions before using it for selection.
