Jichai
Jichai H16V190ZLT-2
190 series
Jichai H16V190ZLT-2 — 97.53 L V16 (190 × 215 mm) spark-ignited natural gas generator engine (CNPC Jichai H16V190 Miller-cycle lean-burn series, genset 1100GF-T (400V) / 1100GF1-T (10.5kV)). 1200 kW engine / 1100 kWe at 1000 rpm / 50 Hz; high-boost intake, closed-loop air-fuel ratio control, heat rate ≤10000 kJ/kWh, NOx ≤500 mg/Nm³@5%O₂.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-06-10
- Package route
- gas generator sets
- Prime Power · 50 Hz
- 1,375 kVA
- Electrical Output
- 1,100 kWe
- Cylinders
- V16
- Displacement
- 97.53 L
- Rated Speed
- 1,000 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 1100 | 1375 |
Ask about Jichai H16V190ZLT-2
Choose parts / service or sourcing. Your message includes this model and page link.
Jichai H16V190ZLT-2 overhaul & repair parts
Already running a Jichai H16V190ZLT-2? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with H16V190ZLT-2 and your selected categories included. Attach your photos there.
Jichai H16V190ZLT-2 generator set context
The Jichai H16V190ZLT-2 is listed here as a natural gas generator-drive engine for 50 Hz generator sets, with a headline 1,375 kVA / 1,100 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | H16V190ZLT-2 |
| Series | 190 series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 97.53 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai H16V190ZLT-2?
The Jichai H16V190ZLT-2 is rated at 1,375 kVA prime at 50 Hz (1,000 rpm).
Does the H16V190ZLT-2 run at 50 Hz or 60 Hz?
The Jichai H16V190ZLT-2 is rated for 50 Hz (1,000 rpm).
What fuel does the Jichai H16V190ZLT-2 use?
The Jichai H16V190ZLT-2 is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the H16V190ZLT-2?
The Jichai H16V190ZLT-2 is a V16 (16-cylinder) engine with a displacement of 97.53 L.
What is the catalog status of the Jichai H16V190ZLT-2?
The Jichai H16V190ZLT-2 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the H16V190ZLT-2?
This page links reference documents for the Jichai H16V190ZLT-2. Check each document's title, model coverage, revision and rating conditions before using it for selection.
