Jichai
Jichai H16V190ZLZ-2
190 series
Jichai H16V190ZLZ-2 — 97.53 L V16 (190 × 215 mm) spark-ignited biogas (沼气) generator engine (CNPC Jichai H16V190 Miller-cycle lean-burn series, gensets 1000GF-Z / 1000GF9-Z). 1200 kW engine / 1000 kWe at 1000 rpm / 50 Hz; high-boost intake, closed-loop AFR; for landfill, wastewater, livestock and food-processing biogas; heat rate ≤10000 kJ/kWh, NOx ≤500 mg/Nm³@5%O₂.
- Prime Power · 50 Hz
- 1,250 kVA
- Electrical Output
- 1,000 kWe
- Cylinders
- V16
- Displacement
- 97.53 L
- Rated Speed
- 1,000 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 1000 | 1250 |
Technical Specifications
| Brand | Jichai |
| Model | H16V190ZLZ-2 |
| Series | 190 series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 97.53 L |
| Fuel Type | Biogas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
