Jichai
Jichai JC130
JC130
Jichai JC130 — 6-cylinder medium-speed marine/land diesel generator engine (CNPC Jichai JC130 series, gensets CCFJ-2000 / CCFJ-1900). 2100 kW engine / 2000 kWe (50 Hz) / 1900 kWe (60 Hz) at 750/720 rpm; runs MGO/MDO/HFO; IMO Tier II / China II; 35,000 h overhaul interval.
- Prime Power · 50 Hz
- 2,500 kVA
- Electrical Output
- 2,000 kWe
- Cylinders
- L6
- Rated Speed
- 750 / 900 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz750 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 2000 | 2500 |
60 Hz900 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 1900 | 2375 |
Jichai JC130 generator set context
The Jichai JC130 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 2,500 kVA / 2,000 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | JC130 |
| Series | JC130 |
| Configuration | L6 |
| Cylinders | 6 |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | IMO Tier II |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai JC130?
The Jichai JC130 is rated at 2,500 kVA prime at 50 Hz (750 rpm); and 2,375 kVA prime at 60 Hz (900 rpm).
Does the JC130 run at 50 Hz or 60 Hz?
The Jichai JC130 is available for both 50 Hz (750 rpm) and 60 Hz (900 rpm).
What fuel does the Jichai JC130 use?
The Jichai JC130 is a diesel generator-set engine.
What is the cylinder configuration of the JC130?
The Jichai JC130 is an inline-6 (6-cylinder) engine.
What emissions standard does the JC130 meet?
The Jichai JC130 is certified to IMO Tier II emissions standards.
Is the Jichai JC130 still in production?
Yes — the Jichai JC130 is a current production model.
