Jichai
Jichai 12V26/32-D
260 series
Jichai 12V26/32-D — 203.9 L V12 (260 × 320 mm) common-rail turbocharged DIESEL generator engine (CNPC Jichai 260 series). 3600–4000 kWe at 900/1000 rpm (60/50 Hz), 400 V–13.8 kV; IMO Tier II / China marine II, ≤180 g/kWh.
- Prime Power · 50 Hz
- 5,000 kVA
- Electrical Output
- 4,000 kWe
- Cylinders
- V12
- Displacement
- 203.9 L
- Rated Speed
- 1,000 / 1,200 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 4000 | 5000 |
60 Hz1200 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 3600 | 4500 |
Jichai 12V26/32-D generator set context
The Jichai 12V26/32-D is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 5,000 kVA / 4,000 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | 12V26/32-D |
| Series | 260 series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 203.9 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | IMO Tier II |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai 12V26/32-D?
The Jichai 12V26/32-D is rated at 5,000 kVA prime at 50 Hz (1,000 rpm); and 4,500 kVA prime at 60 Hz (1,200 rpm).
Does the 12V26/32-D run at 50 Hz or 60 Hz?
The Jichai 12V26/32-D is available for both 50 Hz (1,000 rpm) and 60 Hz (1,200 rpm).
What fuel does the Jichai 12V26/32-D use?
The Jichai 12V26/32-D is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 12V26/32-D?
The Jichai 12V26/32-D is a V12 (12-cylinder) engine with a displacement of 203.9 L.
What emissions standard does the 12V26/32-D meet?
The Jichai 12V26/32-D is certified to IMO Tier II emissions standards.
Is the Jichai 12V26/32-D still in production?
Yes — the Jichai 12V26/32-D is a current production model.
