Jichai
Jichai JC170
JC170
Jichai JC170 — 8-cylinder medium-speed marine/land diesel generator engine (CNPC Jichai JC170 series, gensets CCFJ-2700 / CCFJ-2500). 2800 kW engine / 2700 kWe (50 Hz) / 2500 kWe (60 Hz) at 750/720 rpm; runs MGO/MDO/HFO; IMO Tier II / China II; 35,000 h overhaul interval.
- Prime Power · 50 Hz
- 3,375 kVA
- Electrical Output
- 2,700 kWe
- Cylinders
- L8
- Rated Speed
- 750 / 900 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz750 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 2700 | 3375 |
60 Hz900 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 2500 | 3125 |
Jichai JC170 generator set context
The Jichai JC170 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 3,375 kVA / 2,700 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | JC170 |
| Series | JC170 |
| Configuration | L8 |
| Cylinders | 8 |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | IMO Tier II |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai JC170?
The Jichai JC170 is rated at 3,375 kVA prime at 50 Hz (750 rpm); and 3,125 kVA prime at 60 Hz (900 rpm).
Does the JC170 run at 50 Hz or 60 Hz?
The Jichai JC170 is available for both 50 Hz (750 rpm) and 60 Hz (900 rpm).
What fuel does the Jichai JC170 use?
The Jichai JC170 is a diesel generator-set engine.
What is the cylinder configuration of the JC170?
The Jichai JC170 is an inline-8 (8-cylinder) engine.
What emissions standard does the JC170 meet?
The Jichai JC170 is certified to IMO Tier II emissions standards.
Is the Jichai JC170 still in production?
Yes — the Jichai JC170 is a current production model.
