Jichai
Jichai L16V190ZLT
190 series
Jichai L16V190ZLT — 115.7 L V16 (190 × 255 mm) spark-ignited gas generator engine (CNPC Jichai). 1500–1600 kWe at 1000 rpm; runs natural gas, biogas or coal-mine gas (CBM). CNPC's flagship engine line for oilfield and stationary power.
Overhaul & repair parts- Manufacturer files
- No datasheet
- Last updated
- 2026-06-10
- Package route
- gas generator sets
- Prime Power · 50 Hz
- 2,000 kVA
- Electrical Output
- 1,600 kWe
- Cylinders
- V16
- Displacement
- 115.7 L
- Rated Speed
- 1,000 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 1600 | 2000 |
Ask about Jichai L16V190ZLT
Choose parts / service or sourcing. Your message includes this model and page link.
Jichai L16V190ZLT overhaul & repair parts
Already running a Jichai L16V190ZLT? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with L16V190ZLT and your selected categories included. Attach your photos there.
Jichai L16V190ZLT generator set context
The Jichai L16V190ZLT is listed here as a natural gas generator-drive engine for 50 Hz generator sets, with a headline 2,000 kVA / 1,600 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | L16V190ZLT |
| Series | 190 series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 115.7 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai L16V190ZLT?
The Jichai L16V190ZLT is rated at 2,000 kVA prime at 50 Hz (1,000 rpm).
Does the L16V190ZLT run at 50 Hz or 60 Hz?
The Jichai L16V190ZLT is rated for 50 Hz (1,000 rpm).
What fuel does the Jichai L16V190ZLT use?
The Jichai L16V190ZLT is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the L16V190ZLT?
The Jichai L16V190ZLT is a V16 (16-cylinder) engine with a displacement of 115.7 L.
What is the catalog status of the Jichai L16V190ZLT?
The Jichai L16V190ZLT is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
