Jichai
Jichai L20V190ZLT-2
190 series
Jichai L20V190ZLT-2 — 144.6 L V20 (190 × 255 mm) spark-ignited natural gas generator engine (CNPC Jichai L20V190 lean-burn series, genset 2000GF10-T, 10.5 kV). 2100 kW engine / 2000 kWe at 1000 rpm / 50 Hz; closed-loop air-fuel ratio control, smart cooling, low-pressure-gas capable, heat rate ≤9000 kJ/kWh, NOx ≤469 mg/Nm³@5%O₂.
- Prime Power · 50 Hz
- 2,500 kVA
- Electrical Output
- 2,000 kWe
- Cylinders
- V20
- Displacement
- 144.6 L
- Rated Speed
- 1,000 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 2000 | 2500 |
Jichai L20V190ZLT-2 generator set context
The Jichai L20V190ZLT-2 is listed here as a natural gas generator-drive engine for 50 Hz generator sets, with a headline 2,500 kVA / 2,000 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | L20V190ZLT-2 |
| Series | 190 series |
| Configuration | V20 |
| Cylinders | 20 |
| Displacement | 144.6 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai L20V190ZLT-2?
The Jichai L20V190ZLT-2 is rated at 2,500 kVA prime at 50 Hz (1,000 rpm).
Does the L20V190ZLT-2 run at 50 Hz or 60 Hz?
The Jichai L20V190ZLT-2 is rated for 50 Hz (1,000 rpm).
What fuel does the Jichai L20V190ZLT-2 use?
The Jichai L20V190ZLT-2 is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the L20V190ZLT-2?
The Jichai L20V190ZLT-2 is a V20 (20-cylinder) engine with a displacement of 144.6 L.
Is the Jichai L20V190ZLT-2 still in production?
Yes — the Jichai L20V190ZLT-2 is a current production model.
Is a datasheet available for the L20V190ZLT-2?
Yes — an official Jichai datasheet for the Jichai L20V190ZLT-2 can be downloaded from this page.
