Jichai
Jichai L20V190ZLZ-2
190 series
Jichai L20V190ZLZ-2 — 144.6 L V20 (190 × 255 mm) spark-ignited biogas (沼气) generator engine (CNPC Jichai L20V190 lean-burn series, genset 1500GF-Z, 10.5 kV). 1600 kW engine / 1500 kWe at 1000 rpm / 50 Hz; closed-loop AFR, smart cooling, low-pressure-gas capable; for landfill, wastewater, livestock and food-processing biogas; heat rate ≤9000 kJ/kWh, NOx ≤469 mg/Nm³@5%O₂.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-06-10
- Package route
- gas generator sets
- Prime Power · 50 Hz
- 1,875 kVA
- Electrical Output
- 1,500 kWe
- Cylinders
- V20
- Displacement
- 144.6 L
- Rated Speed
- 1,000 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 1500 | 1875 |
Ask about Jichai L20V190ZLZ-2
Choose parts / service or sourcing. Your message includes this model and page link.
Jichai L20V190ZLZ-2 overhaul & repair parts
Already running a Jichai L20V190ZLZ-2? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with L20V190ZLZ-2 and your selected categories included. Attach your photos there.
Jichai L20V190ZLZ-2 generator set context
The Jichai L20V190ZLZ-2 is listed here as a biogas generator-drive engine for 50 Hz generator sets, with a headline 1,875 kVA / 1,500 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | L20V190ZLZ-2 |
| Series | 190 series |
| Configuration | V20 |
| Cylinders | 20 |
| Displacement | 144.6 L |
| Fuel Type | Biogas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai L20V190ZLZ-2?
The Jichai L20V190ZLZ-2 is rated at 1,875 kVA prime at 50 Hz (1,000 rpm).
Does the L20V190ZLZ-2 run at 50 Hz or 60 Hz?
The Jichai L20V190ZLZ-2 is rated for 50 Hz (1,000 rpm).
What fuel does the Jichai L20V190ZLZ-2 use?
The Jichai L20V190ZLZ-2 is a Biogas generator-set engine.
What is the displacement and cylinder configuration of the L20V190ZLZ-2?
The Jichai L20V190ZLZ-2 is a V20 (20-cylinder) engine with a displacement of 144.6 L.
What is the catalog status of the Jichai L20V190ZLZ-2?
The Jichai L20V190ZLZ-2 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the L20V190ZLZ-2?
This page links reference documents for the Jichai L20V190ZLZ-2. Check each document's title, model coverage, revision and rating conditions before using it for selection.
