Kubota
Kubota D1803-M-DI-BG-CHN-1T
D Series
The Kubota D1803-M-DI-BG-CHN-1T is a 1.803-litre inline-3 diesel engine for generator sets, rated at 19 kVA / 15 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in Japan.
Overhaul & repair parts- Supporting documents
- No documents linked
- Last updated
- 2026-07-01
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 19 kVA
- Electrical Output
- 15 kWe
- Cylinders
- L3
- Displacement
- 1.803 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 15.6 | 14 | 17.5 |
| Standby Power | 16.7 | 15 | 18.8 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 18.9 | 17 | 21.3 |
| Standby Power | 21.1 | 19 | 23.8 |
Ask about Kubota D1803-M-DI-BG-CHN-1T
Choose parts / service or sourcing. Your message includes this model and page link.
Kubota D1803-M-DI-BG-CHN-1T overhaul & repair parts
Already running a Kubota D1803-M-DI-BG-CHN-1T? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with D1803-M-DI-BG-CHN-1T and your selected categories included. Attach your photos there.
Kubota D1803-M-DI-BG-CHN-1T generator set context
The Kubota D1803-M-DI-BG-CHN-1T is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 19 kVA / 15 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Kubota |
| Model | D1803-M-DI-BG-CHN-1T |
| Series | D Series |
| Configuration | L3 |
| Cylinders | 3 |
| Displacement | 1.803 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Kubota D1803-M-DI-BG-CHN-1T?
The Kubota D1803-M-DI-BG-CHN-1T is rated at 19 kVA standby / 18 kVA prime at 50 Hz (1,500 rpm); and 24 kVA standby / 21 kVA prime at 60 Hz (1,800 rpm).
Does the D1803-M-DI-BG-CHN-1T run at 50 Hz or 60 Hz?
The Kubota D1803-M-DI-BG-CHN-1T is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Kubota D1803-M-DI-BG-CHN-1T use?
The Kubota D1803-M-DI-BG-CHN-1T is a diesel generator-set engine.
What is the displacement and cylinder configuration of the D1803-M-DI-BG-CHN-1T?
The Kubota D1803-M-DI-BG-CHN-1T is an inline-3 (3-cylinder) engine with a displacement of 1.803 L.
What is the catalog status of the Kubota D1803-M-DI-BG-CHN-1T?
The Kubota D1803-M-DI-BG-CHN-1T is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
