Kubota
Kubota V1305-E2B-CHN-1
V Series
The Kubota V1305-E2B-CHN-1 is a 1.305-litre inline-4 diesel engine for generator sets, rated at 21 kVA / 17 kWe standby power at 3,000 RPM (50 Hz). It is a liquid-cooled engine built in Japan.
- Standby Power · 50 Hz
- 21 kVA
- Electrical Output
- 17 kWe
- Cylinders
- L4
- Displacement
- 1.305 L
- Rated Speed
- 3,000 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz3000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 17.8 | 16 | 20 |
| Standby Power | 18.9 | 17 | 21.3 |
Technical Specifications
| Brand | Kubota |
| Model | V1305-E2B-CHN-1 |
| Series | V Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 1.305 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Kubota V1305-E2B-CHN-1?
The Kubota V1305-E2B-CHN-1 is rated at 21 kVA standby / 20 kVA prime at 50 Hz (3,000 rpm).
Does the V1305-E2B-CHN-1 run at 50 Hz or 60 Hz?
The Kubota V1305-E2B-CHN-1 is rated for 50 Hz (3,000 rpm).
What fuel does the Kubota V1305-E2B-CHN-1 use?
The Kubota V1305-E2B-CHN-1 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the V1305-E2B-CHN-1?
The Kubota V1305-E2B-CHN-1 is an inline-4 (4-cylinder) engine with a displacement of 1.305 L.
Is the Kubota V1305-E2B-CHN-1 still in production?
Yes — the Kubota V1305-E2B-CHN-1 is a current production model.
