Kubota
Kubota V1505-T-E3B-EU-Z1
V Series
The Kubota V1505-T-E3B-EU-Z1 is a 1.505-litre inline-4 diesel engine for generator sets, rated at 33 kVA / 26 kWe standby power at 3,000 RPM (50 Hz). It is a liquid-cooled engine built in Japan. It meets China Nonroad Stage IV emissions standards.
Get help with this engine
Tell Haifeng whether you already own a Kubota V1505-T-E3B-EU-Z1 engine/generator or need to source this model for a project.
- Manufacturer files
- 1 datasheet
- Last updated
- 2026-07-01
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 33 kVA
- Electrical Output
- 26 kWe
- Cylinders
- L4
- Displacement
- 1.505 L
- Rated Speed
- 3,000 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz3000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 26.7 | 24 | 30 |
| Standby Power | 28.9 | 26 | 32.5 |
Kubota V1505-T-E3B-EU-Z1 generator set context
The Kubota V1505-T-E3B-EU-Z1 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 33 kVA / 26 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Kubota |
| Model | V1505-T-E3B-EU-Z1 |
| Series | V Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 1.505 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China Nonroad Stage IV |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Kubota V1505-T-E3B-EU-Z1?
The Kubota V1505-T-E3B-EU-Z1 is rated at 33 kVA standby / 30 kVA prime at 50 Hz (3,000 rpm).
Does the V1505-T-E3B-EU-Z1 run at 50 Hz or 60 Hz?
The Kubota V1505-T-E3B-EU-Z1 is rated for 50 Hz (3,000 rpm).
What fuel does the Kubota V1505-T-E3B-EU-Z1 use?
The Kubota V1505-T-E3B-EU-Z1 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the V1505-T-E3B-EU-Z1?
The Kubota V1505-T-E3B-EU-Z1 is an inline-4 (4-cylinder) engine with a displacement of 1.505 L.
What emissions standard does the V1505-T-E3B-EU-Z1 meet?
The Kubota V1505-T-E3B-EU-Z1 is certified to China Nonroad Stage IV emissions standards.
Is the Kubota V1505-T-E3B-EU-Z1 still in production?
Yes — the Kubota V1505-T-E3B-EU-Z1 is a current production model.
Is a datasheet available for the V1505-T-E3B-EU-Z1?
Yes — an official Kubota datasheet for the Kubota V1505-T-E3B-EU-Z1 can be downloaded from this page.
