Kubota V1505-E2BG-CHN-1
V Series
The Kubota V1505-E2BG-CHN-1 is a 1.505-litre inline-4 diesel engine for generator sets, rated at 14 kVA / 11 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in Japan.
Overhaul & repair parts- Supporting documents
- No documents linked
- Last updated
- 2026-07-01
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 14 kVA
- Electrical Output
- 11 kWe
- Cylinders
- L4
- Displacement
- 1.505 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 11.1 | 10 | 12.5 |
| Standby Power | 12.2 | 11 | 13.8 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 13.3 | 12 | 15 |
| Standby Power | 15.6 | 14 | 17.5 |
Ask about Kubota V1505-E2BG-CHN-1
Choose parts / service or sourcing. Your message includes this model and page link.
Kubota V1505-E2BG-CHN-1 overhaul & repair parts
Already running a Kubota V1505-E2BG-CHN-1? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with V1505-E2BG-CHN-1 and your selected categories included. Attach your photos there.
Kubota V1505-E2BG-CHN-1 generator set context
The Kubota V1505-E2BG-CHN-1 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 14 kVA / 11 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Kubota |
| Model | V1505-E2BG-CHN-1 |
| Series | V Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 1.505 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Kubota V1505-E2BG-CHN-1?
The Kubota V1505-E2BG-CHN-1 is rated at 14 kVA standby / 13 kVA prime at 50 Hz (1,500 rpm); and 18 kVA standby / 15 kVA prime at 60 Hz (1,800 rpm).
Does the V1505-E2BG-CHN-1 run at 50 Hz or 60 Hz?
The Kubota V1505-E2BG-CHN-1 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Kubota V1505-E2BG-CHN-1 use?
The Kubota V1505-E2BG-CHN-1 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the V1505-E2BG-CHN-1?
The Kubota V1505-E2BG-CHN-1 is an inline-4 (4-cylinder) engine with a displacement of 1.505 L.
What is the catalog status of the Kubota V1505-E2BG-CHN-1?
The Kubota V1505-E2BG-CHN-1 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
