Kubota
Kubota V1505-E4BG1-SAE-2X
V Series
The Kubota V1505-E4BG1-SAE-2X is a 1.505-litre inline-4 diesel engine for generator sets, rated at 18 kVA / 14 kWe standby power at 1,800 RPM (60 Hz). It is a liquid-cooled engine built in Japan. It meets U.S. EPA Final Tier 4 emissions standards.
- Standby Power · 60 Hz
- 18 kVA
- Electrical Output
- 14 kWe
- Cylinders
- L4
- Displacement
- 1.505 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 13.3 | 12 | 15 |
| Standby Power | 15.6 | 14 | 17.5 |
Technical Specifications
| Brand | Kubota |
| Model | V1505-E4BG1-SAE-2X |
| Series | V Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 1.505 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Final Tier 4 |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Kubota V1505-E4BG1-SAE-2X?
The Kubota V1505-E4BG1-SAE-2X is rated at 18 kVA standby / 15 kVA prime at 60 Hz (1,800 rpm).
Does the V1505-E4BG1-SAE-2X run at 50 Hz or 60 Hz?
The Kubota V1505-E4BG1-SAE-2X is rated for 60 Hz (1,800 rpm).
What fuel does the Kubota V1505-E4BG1-SAE-2X use?
The Kubota V1505-E4BG1-SAE-2X is a diesel generator-set engine.
What is the displacement and cylinder configuration of the V1505-E4BG1-SAE-2X?
The Kubota V1505-E4BG1-SAE-2X is an inline-4 (4-cylinder) engine with a displacement of 1.505 L.
What emissions standard does the V1505-E4BG1-SAE-2X meet?
The Kubota V1505-E4BG1-SAE-2X is certified to U.S. EPA Final Tier 4 emissions standards.
Is the Kubota V1505-E4BG1-SAE-2X still in production?
Yes — the Kubota V1505-E4BG1-SAE-2X is a current production model.
Is a datasheet available for the V1505-E4BG1-SAE-2X?
Yes — an official Kubota datasheet for the Kubota V1505-E4BG1-SAE-2X can be downloaded from this page.
