Mitsubishi
Mitsubishi S16R2-PTAW2-E
S16R2 Series
Mitsubishi S16R2-PTAW2-E 79.900L V16 constant-speed diesel engine for generator applications. Official MHI output without fan - 50 Hz: prime 2209 kWm at 1500 rpm, standby 2430 kWm at 1500 rpm. Emissions: Unregulated.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-07-23
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 2,886 kVA
- Electrical Output
- 2,309 kWe
- Cylinders
- V16
- Displacement
- 79.9 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 2209 | 2098.4 | 2623 |
| Standby Power | 2430 | 2308.8 | 2886 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Ask about Mitsubishi S16R2-PTAW2-E
Choose parts / service or sourcing. Your message includes this model and page link.
Mitsubishi S16R2-PTAW2-E overhaul & repair parts
Already running a Mitsubishi S16R2-PTAW2-E? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with S16R2-PTAW2-E and your selected categories included. Attach your photos there.
Mitsubishi S16R2-PTAW2-E generator set context
The Mitsubishi S16R2-PTAW2-E is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 2,886 kVA / 2,309 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Mitsubishi |
| Model | S16R2-PTAW2-E |
| Series | S16R2 Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 79.9 L |
| Dry Weight | 7750 kg |
| Dimensions (L×W×H) | 3118 × 1505 × 2030 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Mitsubishi S16R2-PTAW2-E?
The Mitsubishi S16R2-PTAW2-E is rated at 2,886 kVA standby / 2,623 kVA prime at 50 Hz (1,500 rpm).
Does the S16R2-PTAW2-E run at 50 Hz or 60 Hz?
The Mitsubishi S16R2-PTAW2-E is rated for 50 Hz (1,500 rpm).
What fuel does the Mitsubishi S16R2-PTAW2-E use?
The Mitsubishi S16R2-PTAW2-E is a diesel generator-set engine.
What is the displacement and cylinder configuration of the S16R2-PTAW2-E?
The Mitsubishi S16R2-PTAW2-E is a V16 (16-cylinder) engine with a displacement of 79.9 L.
What is the catalog status of the Mitsubishi S16R2-PTAW2-E?
The Mitsubishi S16R2-PTAW2-E is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the S16R2-PTAW2-E?
This page links reference documents for the Mitsubishi S16R2-PTAW2-E. Check each document's title, model coverage, revision and rating conditions before using it for selection.
