Mitsubishi
Mitsubishi S6R-Y2PTAW
S6R Series
Mitsubishi S6R-Y2PTAW 24.510L L6 constant-speed diesel engine for generator applications. Official MHI output without fan - 60 Hz: prime 623 kWm at 1800 rpm, standby 685 kWm at 1800 rpm. Emissions: Unregulated (prime); U.S. EPA Tier 2 (standby).
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-07-23
- Package route
- diesel generator sets
- Standby Power · 60 Hz
- 813 kVA
- Electrical Output
- 650 kWe
- Cylinders
- L6
- Displacement
- 24.51 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 623 | 592 | 740 |
| Standby Power | 685 | 650.4 | 813 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Ask about Mitsubishi S6R-Y2PTAW
Choose parts / service or sourcing. Your message includes this model and page link.
Mitsubishi S6R-Y2PTAW overhaul & repair parts
Already running a Mitsubishi S6R-Y2PTAW? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with S6R-Y2PTAW and your selected categories included. Attach your photos there.
Mitsubishi S6R-Y2PTAW generator set context
The Mitsubishi S6R-Y2PTAW is listed here as a diesel generator-drive engine for 60 Hz generator sets, with a headline 813 kVA / 650 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Mitsubishi |
| Model | S6R-Y2PTAW |
| Series | S6R Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 24.51 L |
| Dry Weight | 2705 kg |
| Dimensions (L×W×H) | 1872 × 1083 × 1498 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Mitsubishi S6R-Y2PTAW?
The Mitsubishi S6R-Y2PTAW is rated at 813 kVA standby / 740 kVA prime at 60 Hz (1,800 rpm).
Does the S6R-Y2PTAW run at 50 Hz or 60 Hz?
The Mitsubishi S6R-Y2PTAW is rated for 60 Hz (1,800 rpm).
What fuel does the Mitsubishi S6R-Y2PTAW use?
The Mitsubishi S6R-Y2PTAW is a diesel generator-set engine.
What is the displacement and cylinder configuration of the S6R-Y2PTAW?
The Mitsubishi S6R-Y2PTAW is an inline-6 (6-cylinder) engine with a displacement of 24.51 L.
What emissions information is listed for the S6R-Y2PTAW?
This record lists U.S. EPA Tier 2 for the Mitsubishi S6R-Y2PTAW. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Mitsubishi S6R-Y2PTAW?
The Mitsubishi S6R-Y2PTAW is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the S6R-Y2PTAW?
This page links reference documents for the Mitsubishi S6R-Y2PTAW. Check each document's title, model coverage, revision and rating conditions before using it for selection.
